详细参数
CPU    • 四核Cortex-A72 + 四核Cortex-A53，频率最高2.2GHz
GPU    • ARM G52 MC3
NPU    • 6TOPS* RKNN
PQ    • Rockchip dedicated Picture Quality Engine (HDR, ACM, DCI, etc.)
显示    • DisplayPort/MIPI/eDP/HDMI/RGB/EBC , 多屏异显
内存    • 32bits LPDDR4/4x, LPDDR5
• UFS 2.0 (2-lane), eMMC 5.1, SPI Nor/Nand
视频    • 8K30 H.264/H.265/VP9/AV2/AVS2 Decoder
• 4K60 H.264/H.265 Encoder
Camera    • 16M ISP with HDR (up to 120dB)
• MIPI CSI-2 (CDPHY=1*4-lane, DPHY=2*4-lane/4*2-lane), DVP
接口    • 5 SAI interfaces (total 7-tx and 7-rx lanes, each lane supports 8-ch I2S/PCM/TDM)
• 2 PCM (2*8-ch)
• 2 S/PDIF TX and 1 S/PDIF RX
• ASRC
• USB 3.0 DRD (supports Alt mode with DP)
• Combo USB3.0 DRD/PCIe 2.1 RC/SATA3
• Combo PCIe 2.1 RC/SATA3
• RGMIIx2
• CAN FD, DSMC
• UART, SPI, PWM, I2C, SAR-ADC
